5JW-IN JIC PÁNSKÉ 74 ° KONEČNĚ / INCH SOCKET-WELD TUBE tabulka velikostí takto:
PAR T NE . | THREA D | D | ROZMĚRY S | ||
E | WEL D TUB E O. D D | A | L | S 1 | |
5JW-04I N | 7/16 "X2 0 | 1/4 " | 1 4 | 2 3 | 1 4 |
5JW-04-05I N | 7/16 "X2 0 | 5/16 " | 1 4 | 2 3 | 1 4 |
5JW-05I N | 1/2 " X 2 0 | 5/16 " | 1 4 | 2 3 | 1 4 |
5JW-06I N | 9/16 "X1 8 | 3/8 " | 14.1 | 2 4 | 1 7 |
5JW-08I N | 3/4 "X1 6 | 1/2 " | 16,7 | 29. 5 | 2 2 |
5JW-08-06I N | 3/4 "X1 6 | 3/8 " | 16,7 | 29,5 | 2 2 |
5JW-08-10I N | 3/4 "X1 6 | 5/8 " | 16,7 | 29,5 | 2 4 |
5JW-08-12I N | 3/4 "X1 6 | 3/4 " | 16,7 | 29,5 | 2 4 |
5JW-10I N | 7/8 "X1 4 | 5/8 " | 19. 3 | 3 2 | 2 4 |
5JW-10-08I N | 7/8 "X1 4 | 1/2 " | 19. 3 | 3 2 | 2 4 |
5JW-10-12I N | 7/8 "X1 4 | 3/4 " | 19. 3 | 3 5 | 3 0 |
5JW-12I N | 1,1 / 16 "X1 2 | 3/4 " | 2 2 | 3 8 | 3 0 |
5JW-12-08I N | 1,1 / 16 "X1 2 | 1/2 " | 2 2 | 3 7 | 3 0 |
5JW-12-10I N | 1,1 / 16 "X1 2 | 5/8 " | 2 2 | 3 7 | 3 0 |
5JW-12-16I N | 1,1 / 16 "X1 2 | 1 " | 2 2 | 3 9 | 3 6 |
5JW-14I N | 1 . 3/16 " X 1 2 | 7/8 " | 22,6 | 39,5 | 3 6 |
5JW-16I N | 1,5 / 16 "X1 2 | 1 " | 2 3 | 4 0 | 3 6 |
5JW-16-20I N | 1,5 / 16 "X1 2 | 1,1 / 4 " | 2 3 | 4 1 | 4 1 |
5JW-20I N | 1,5 / 8 "X1 2 | 1,1 / 4 " | 24. 3 | 4 3 | 4 6 |
5JW-20-16I N | 1,5 / 8 "X1 2 | 1 " | 24 .3 | 4 3 | 4 6 |
5JW-20-24I N | 1,5 / 8 "X1 2 | 1,1 / 2 " | 24 .3 | 45,5 | 5 0 |
5JW-24I N | 1,7 / 8 "X1 2 | 1,1 / 2 " | 27. 5 | 48. 5 | 5 0 |
5JW-24-20I N | 1,7 / 8 "X1 2 | 1,1 / 4 " | 27. 5 | 48,5 | 5 0 |
5JW-32I N | 2 . 1/2 " X 1 2 | 2 " | 33,9 | 5 5 | 6 5 |
D NB20 0 NB50 0 NB20 0 NB30 0 Nu t d rukáv e shoul d b e ordere d samostatně nu t NB20 0 d rukáv e NB50 0 je vhodný pro r metri c trubice, e nu t NB20 0 d rukáv e NB30 0 já s e pro r vč trubice . | |||||
